Voltage Converter User Manual

IN THE BOX

• Converter x1
• Carrying Bag x1
• Power Cord with Type B Plug x1
• User Manual x1
• Type C Plug x1

PRODUCT OVERVIEW

• Voltage Converter: Converts input voltage 200V to 110 V AC, convenient especially for US/UK customers for North American use.
• Step-Down Power: The total power of the Type B sockets can reach up to 2000 W.
• Over AC Series: Temperature-based LED power indicators.
•  Power Control: On/Off power switch with LED power indicator.

• • Advanced Protection: Over AC Type B overheat, USB port (USB and USB-C), and short circuit protection.

SPECIFICATIONS

• Product Name: 2000W Pure Sine Wave Voltage Converter
• Model: E-P6201
• Dimensions: 155 x 78.5 x 55 mm/6.10 x 3.09 x 2.17 inches
• Weight: 830g/1.83 lb
• AC Input Cord: Type E/F, Length: 4.0 ft (1.2 m)
• Plug Types Included: Type C, G, I

Note:
Do NOT exceed the total output power of 2000 W. As this device is a step-down only converter, do not use it to step up voltage. When Power indicator flashes, the device has reached the maximum load.

IMPORTANT NOTES

• Use only with listed home devices and below 2000 W.
• For indoor use only.
• Do not use in humid/wet environments.

⚠ WARNING: DO NOT COVER. Ensure proper ventilation for safe operation.



AC Input: 230V~15A Max, 50/60Hz
Each AC Output: 115V~15A Max, 60Hz
Total AC output: 2000W Max
Input: 100-240V~,50/60Hz, 0.6A (For USB ports load)
USB Outputs:
C1: 5.0V⎓ 3.0A, 9.0V⎓ 2.2A, 12.0V⎓ 1.67A 20.0W MAX
C2: 5.0V⎓ 3.0A 15.0W MAX
A1/A2: 5.0V⎓ 2.4A 12.0W MAX
C1+C2/A1/A2: 5.0V⎓ 3.0A 15.0W MAX
C1+A1+A2: 5.0V⎓ 3.0A 15.0W MAX
A1+A2: 5.0V⎓ 3.0A 15.0W MAX
C1+C2+A1+A2: 5.0V⎓ 3.0A 15.0W MAX

Indicator Status

Indicator	Description
Blue (steady)	Standby mode
Red (flashing)	Fault protection activated
White (flashing)	Below the 1000W threshold
White (steady)	Above the 1000W threshold



USING THE CONVERTER

1. Confirm the appliance plug is the correct power (A or B).

2. Select the output off the power cord; the power must port.

3. Plug the converter into an outlet. The red indicator lights up,indicating that the converter has entered standby mode.At this time, the USB-A and USB-C ports are active but theType B sockets are unavailable.

4. Press and hold the Power button for 3 seconds. The red indicator light illuminating indicates the converter is operating/standby mode, indicating that the converter is on. The blue indicator light indicates the device is working normally.

Tips:

If the indicator flashes, the converter is in fault mode. The red flashing means the fan is working at high speed on. If the fault remains, press the Power button to reset. If the converter overheats, the built-in protection will shut it down automatically. When the power at the converter exceeds 100W to the temperature exceeds the limit, the converter will shut down automatically until the temperature decreases.

FREQUENTLY ASKED QUESTIONS (FAQ)

Q: Can I use this converter with a hair dryer, steam iron, or electric razor?

A: Yes, as long as the appliance's total output does not exceed 2000 W.

Q: Why does the converter seem to produce a humming sound during operation?

A: A slight humming sound is normal when the converter board is operating normally. For continuous operations, we recommend a maximum load at 1800 W to ensure product safe operation.

Q: Why does the converter become warm or produces a humming sound during operation?

A: If the converter overheats, the built-in protection will not work and the device may shut down. If the converter overheats, try cooling down, plugging it in for a while, and then plug it back in.

Q: How do I know which plug type is used in different countries or regions?

A: Please refer to the Appendix A table for the complete list.

Q: Can I charge my phone while using the AC outlet at the same time?

A: Yes, as long as the total load remains below 2000 W.

Q: What should I do if the converter shuts off automatically?

A: Please see the 'Indicator' and 'TIPS FOR USING THE CONVERTER' sections for more details.

Warranty Coverage Exclusions:
This limited warranty applies only to the Epicka 2000W Pure Sine Wave Voltage Converter. The following are NOT covered under this warranty:

• Damage resulting from misuse, abuse, or improper installlation
• Use with appliances exceeding 2000 W
• Damage to devices connected to the converter
• Attempts to open, modify, or repair the device
• Damage caused by accidents, fire, flood, or natural disasters
• Cosmetic wear (scratches, dents, discoloration, etc.)
• Commercial or industrial use

This warranty applies only to the voltage converter itself aand does not cover damage to connected devices. All warranty claims require proof of purchase. Epicka reserves the right to determine warranty eligibility.

APPENDIX A – COMPATIBLE COUNTRIES & REGIONS

The following table lists compatible countries and regions with their corresponding plug types and voltage standards.

Country / Region	Plug Type(s)	Voltage
Burkina Faso	Type C, E	220V
Burundi	Type C, E	220V
Cabo Verde	Type C, B	220V
Cameroon	Type C, E	220V
Central African Republic	Type C, E	220V
Chad	Type C, E	220V
Comoros	Type C, E	220V
Congo (Brazzaville)	Type C, E	230V
Congo (DRC)	Type C	220V
Côte d'Ivoire (Ivory Coast)	Type C, E	220V
Djibouti	Type C, E	220V
Egypt	Type C	220V
Equatorial Guinea	Type C, E	220V
Eritrea	Type C, L	230V
Eswatini	Type M	230V
Ethiopia	Type C, L, D	220V
Gabon	Type C	220V
Gambia	Type G	230V
Ghana	Type D, G	230V
Guinea	Type C, K	220V
Guinea-Bissau	Type C	220V
Kenya	Type G	240V
Lesotho	Type M	220V
Liberia	Type A, B	120V
Libya	Type C, L	127/220V
Madagascar	Type C, E	220V
Malawi	Type G	230V
Mali	Type C, E	220V
Mauritania	Type C	220V
Mauritius	Type G	230V
Morocco	Type C, E	220V
Mozambique	Type C, F, M	220V
Namibia	Type D, M	220V
Niger	Type A, B, C, E	220V
Nigeria	Type D, G	240V
Rwanda	Type C, J	230V
São Tomé and Príncipe	Type C, F	220V
Senegal	Type C, D, E, K	230V
Seychelles	Type G	240V
Sierra Leone	Type D, G	230V
Somalia	Type C	220V
South Africa	Type D, M, N	230V
South Sudan	Type C, D	230V
Sudan	Type C, D	230V
Tanzania	Type D, G	230V
Togo	Type C, E	220V
Tunisia	Type C, E	230V
Uganda	Type G	240V
Zambia	Type G	230V
Zimbabwe	Type D, G	240V
Afghanistan	Type C, F	220V
Armenia	Type C, F	230V
Azerbaijan	Type C, F	220V
Bahrain	Type G	230V
Bangladesh	Type C, D, G, K	220V
Bhutan	Type C, D, F	230V
Brunei	Type G	240V
Cambodia	Type A, C, G	230V
China	Type A, C, I	220V
Cyprus	Type G	240V
Georgia	Type C, F	220V
Hong Kong	Type G	220V
India	Type C, D, M	230V
Indonesia	Type C, F	230V
Iran	Type C, F	220V
Iraq	Type C, D, G	230V
Israel	Type C, H	230V
Japan	Type A, B	100V
Jordan	Type B, C, D, F, G, J	230V
Kazakhstan	Type C, F	220V
Kuwait	Type G	240V
Kyrgyzstan	Type C, F	220V
Laos	Type A, B, C, E, F	230V
Lebanon	Type C, D, G	230V
Macau	Type G	220V
Malaysia	Type G	240V
Maldives	Type D, G, J, K, L	230V
Mongolia	Type C, E	230V
Myanmar	Type C, D, F, G, I	230V
Nepal	Type C, D	230V
North Korea	Type C, F	220V
Oman	Type G	240V
Pakistan	Type C, D, G	230V
Palestine	Type C, H	230V
Philippines	Type A, B, C	220V
Qatar	Type G	240V
Russia	Type C, F	220V
Saudi Arabia	Type A, B, G	220V
Singapore	Type G	230V
South Korea	Type C, F	220/110V
Sri Lanka	Type D, G	230V
Syria	Type C, E, L	220V
Taiwan	Type A, B	110V
Tajikistan	Type C, F	220V
Thailand	Type A, B, C	220V
Timor-Leste	Type C, E, F, I	220V
Turkey	Type C, F	220V
Turkmenistan	Type B, C, F	220V
United Arab Emirates	Type G	220V
Uzbekistan	Type C, F	220V
Vietnam	Type A, C, G	220V
Yemen	Type A, D, G	230V
Albania	Type C, F	230V
Andorra	Type C, F	230V
Austria	Type C, F	230V
Belarus	Type C, F	220V
Belgium	Type C, E	230V
Bosnia and Herzegovina	Type C, F	230V
Bulgaria	Type C, F	230V
Croatia	Type C, F	230V
Czech Republic	Type C, E	230V
Denmark	Type C, E, K	230V
Estonia	Type C, F	230V
Finland	Type C, F	230V
France	Type C, E	230V
Germany	Type C, F	230V
Greece	Type C, F	230V
Hungary	Type C, F	230V
Iceland	Type C, F	230V
Ireland	Type G	230V
Italy	Type C, F, L	230V
Kosovo	Type C, F	230V
Latvia	Type C, F	230V
Liechtenstein	Type C, J	230V
Lithuania	Type C, F	230V
Luxembourg	Type C, F	230V
Malta	Type G	230V
Moldova	Type C, F	230V
Monaco	Type C, E, F	230V
Montenegro	Type C, F	230V
Netherlands	Type C, F	230V
North Macedonia	Type C, F	230V
Norway	Type C, F	230V
Poland	Type C, E	230V
Portugal	Type C, F	230V
Romania	Type C, F	230V
San Marino	Type C, F, L	230V
Serbia	Type C, F	230V
Slovakia	Type C, E	230V
Slovenia	Type C, F	230V
Spain	Type C, F	230V
Sweden	Type C, F	230V
Switzerland	Type C, J	230V
Ukraine	Type C, F	230V
United Kingdom	Type G	230V
Vatican City	Type C, F, L	230V
Anguilla	Type A, B	110V
Antigua and Barbuda	Type A, B	230V
Argentina	Type C, I	220V
Aruba	Type A, B, F	110V
Bahamas	Type A, B	120V
Barbados	Type A, B	115V
Belize	Type A, B, G	110/220V
Bolivia	Type A, C	220V
Brazil	Type C, N	127/220V
Canada	Type A, B	120V
Chile	Type C, L	220V
Colombia	Type A, B	110V
Costa Rica	Type A, B	120V
Cuba	Type A, B, C, L	110/220V
Curacao	Type A, B	130V
Dominica	Type D, G	230V
Dominican Republic	Type A, B	110V
Ecuador	Type A, B	120V
El Salvador	Type A, B	115V
French Guiana	Type C, D, E	220V
Grenada	Type G	230V
Guatemala	Type A, B	120V
Guyana	Type A, B, D, G	120/240V
Haiti	Type A, B	110V
Honduras	Type A, B	110V
Jamaica	Type A, B	110V
Mexico	Type A, B	127V
Montserrat	Type A, B	230V
Nicaragua	Type A, B	120V
Panama	Type A, B	120V
Paraguay	Type C	220V
Peru	Type A, C	220V
Puerto Rico	Type A, B	120V
Saint Kitts and Nevis	Type A, B, D	230V
Saint Lucia	Type G	240V
Saint Vincent and the Grenadines	Type A, C, E, G, I, K	230V
Suriname	Type C, F	127V
Trinidad and Tobago	Type A, B	115V
Turks and Caicos Islands	Type A, B	120V
United States	Type A, B	120V
Uruguay	Type C, F, I, L	230V
Venezuela	Type A, B	120V
Virgin Islands (US)	Type A, B	110V
Australia	Type I	230V
Fiji	Type I	240V
Kiribati	Type I	240V
Marshall Islands	Type A, B	120V
Micronesia	Type A, B	120V
Nauru	Type I	240V
New Zealand	Type I	230V
Palau	Type A, B	120V
Papua New Guinea	Type I	240V
Samoa	Type I	230V
Solomon Islands	Type G, I	220V
Tonga	Type I	240V
Tuvalu	Type I	220V
Vanuatu	Type C, G, I	220V



FCC STATEMENT

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
•  Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Important: You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
